We set ourselves the task of designing a slit lamp to exceed performance expectations. Our painstaking attention to detail has helped us to achieve just this.
Digital Slit Lamp 3 Megapixel: 2056 x 1542 USB 3 Camera Kapture Software Lower Illumination 3 Step Drum (10x, 16x, 25x)
KSL-Z5- D
Digital Slit Lamp 3 Megapixel: 2056 x 1542 USB 3 Camera Kapture Software Lower Illumination 5 Step Drum (6x, 10x, 16x, 25x, 40x)
Available Add-On:
AOS Slit Diagnostic Software
Keeler optics paired with a unique LED illumination system featuring 360 degree slit rotation and with all the filters and apertures you’ll need.
Available in 3 configurations;
Digital
Digital Ready
Standard
3 Step or 5 Step
Available with either a 3 step drum change for 10 x to 25 x magnifications or a 5 step drum change for x 6 to x 40 magnifications.
Converging or Parallel binoculars
Traditionally most Slit Lamp users prefer converging binoculars, but, many will prefer parallel binoculars for longer procedures or if they have used parallel systems in the past. We offer you the choice of either option.
Digital
Whether for patient or patient family education or for clinical record keeping digital systems are growing in popularity at an increasing pace.
The Z Series Digital has our own Camera / Beamsplitter system, joystick trigger, on board camera controls, a diffuser and integral background illumination system.
Included as standard are the 1mm square aperture for uveitis assessment, a yellow fluorescein barrier filter and the ability to decouple or offset the slit.
Standard version Features
Keeler optics
British built
Stylish and contemporary design
Converging or parallel binoculars
14mm Slit length / maximum aperture
5 step or 3 step magnification systems (X 6 to x 40 or X 10 to X 25)
Blue, red-free, clear, neutral density and diffuser filters
360 degree continuous slit rotation
Slit offset / decoupling
Integrated yellow barrier filter
1m Square aperture for Uveitis assessment
LED illumination
Illumination control mounted next to joystick
3 year warranty
Digital version Features
Feature and function rich Kapture Lite Video software
Trigger function on joystick
Camera exposure controls on Slit Lamp base
LED fibre optic background illumination system
USB 2 Camera and beam splitter system
USB hub integrated in Slit Lamp base
LED illumination
Illumination control mounted next to joystick
3 year warranty
“The Slit Lamp has excellent optics and represents excellent value for money - highly recommended”
Mr. Eric Ezra, Director of Vitreoretinal Surgery, Moorfields Eye Hospital
"I would suggest that LED sources should now be considered the standard for Slit Lamps"
